1984-00 Mopar Wiring Harness
This harness prevents you from having to cut your vehicle's factory wiring harness when installing your RetroSound radio.
670 Wire Code Chart
Power Harness
Wire Color |
Function |
| Red | +12 Volt Accessory |
| Yellow | +12 Volt Constant |
| Empty | (none) |
| Orange | Illumination |
| Empty | (none) |
| White/Black | Left Front Speaker - |
| Gray/Black | Right Front Speaker - |
Speaker Harness
Wire Color |
Function |
|
Blue |
Power Antenna |
|
White |
Left Front Speaker + |
|
Gray |
Right Front Speaker + |
|
Green |
Left Rear Speaker + |
|
Green/Black |
Left Rear Speaker - |
|
Violet |
Right Rear Speaker + |
|
Violet/Black |
Right Rear Speaker - |
Note: Please refer to product packaging for the most up to date country of origin.
